Part Number |
Qty |
Description |
| Air Shroud |
MCP-310-49003-0N |
1 |
SC846 Intel DP X9, X8 PC air shroud 1368x13/12x13MB |
| HD Backplane |
BPN-SAS3-846EL2 |
1 |
24-port 4U SAS3 12Gbps dual-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD |
| Control Board |
CSE-PTJBOD-CB3 |
1 |
JBOD chassis power control board with IPMI remote on/off feature |
| Cable(S) |
CBL-0071L |
1 |
CBL,FRONT CNTL,16 TO 16 PIN,RA,RND TUBE,75CM,28AWG |
| Cable(S) |
CBL-0160L |
2 |
NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt) |
| Cable(S) |
CBL-0217L |
1 |
CBL,CNTL PANEL CONVERTER,FOR SC826/846,FFC,16PIN,22CM |
| Cable(S) |
CBL-0296L |
2 |
4 pin to 4 pin fan extension cord, for PWM fan. 23cm. 24AWG |
| Cable(S) |
CBL-CDAT-0601 |
1 |
CBL,I2C,1X4F/P2.5 TO 1X4F/P2.5,50CM,26AWG,BRN/BLK-SHUNT/ORG |
| Cable(S) |
CBL-NTWK-0587 |
1 |
INT RJ45M/RJ45F Adapter W/ PCB 50CM 24AWG for SC847D JBOD |
| Cable(S) |
CBL-SAST-0593-01 |
8 |
MINI SAS HD,12G,INT,60CM,30AWG |
| Fan(s) |
FAN-0125L4 |
2 |
80x32 mm 6.7K RPM SC836 Rear Exhaust Fan w/ Housing |
| Fan(s) |
FAN-0127L4 |
3 |
80x80x38 mm 7K RPM SC846 Middle Fan w/ Housing |
| Front Panel |
MCP-280-82601-0N |
1 |
Front control board adapter (TB826) for SC216,826,936,846 |
| Drive Tray(s) |
MCP-220-00075-0B |
24 |
Black gen 5.5 hot-swap 3.5"; HDD tray |
| Power Distributor |
PDB-PT846-2824 |
1 |
PDB with 23pairs input connector support SC846B |
| Part(s) |
MCP-260-00011-0N |
1 |
I/O shield without any opening |
| Power Supply & Accessory |
MCP-290-84604-0N |
1 |
SC846 PDB Cover |
| Power Supply & Accessory |
PWS-1K03A-1R |
2 |
1U 1000W Redundant Power Supply Titanium W/PMbus 76x365x40mm,RoHS/REACH |
| Mounting Rail(s) |
MCP-410-00007-0N |
1 |
Rail screw bag |
| Mounting Rail(s) |
MCP-290-00057-0N |
1 set |
Rail set, quick/quick, default for 4U 17.2"; W |
| Rear Window |
MCP-240-84602-0N |
1 |
846B rear window which support 2 X 2.5"; HDD module and DVD
|
