Components Cases 3U Supermicro CSE-836BE1C-R1K03JBOD

Supermicro CSE-836BE1C-R1K03JBOD

Supermicro CSE-836BE1C-R1K03JBOD

1. 3U Storage JBOD Chassis with capacity 16 x 3.5" hot-swappable HDDs bays 2. Single Expander Backplane Boards support SAS3/2 HDDs with 12Gb/s throughput 3. 4 x Mini-SAS HD ports for Internal / External Cascading Expander Combination for high performance, high availability or high redundancy requirements 4. 1x IPMI port for Remote System Power on/off and system monitoring 5. Support NTP for time synchronization & RTC battery backup 6. 1000W (1+1) 96% efficient Titanium level power supplies 7. 5 hot-plug redundant cooling fans 8. Ideal for Cloud backup, data Replication or High desnsity Archive Storage Applications 9. Qualified SAS HBA / controller: AOC-SAS3-9300-8E - 12Gb/s 2-external ports SAS3 HBA AOC-SAS3-9380-8E - 12Gb/s 2-external ports SAS3 RAID Controller

We also offer six months of free collocation in our TIER III data center.

Components are not the end — ask us for a custom server configuration. We will design the server, assemble it, expertly set it up, and provide extended or NBD warranty.

Product code 202.151221
Part number CSE-836BE1C-R1K03JBOD
EAN 672042195749
Manufacturer Supermicro
Availability
In stock 0 pc
Stock allocation and delivery options
Transport company across Europe
Monday 23. 6. at the latest Friday 27. 6.
Supplier availability In stock 1 pc
Warranty 24 months
Weight 29.7 kg
The price includes all legal fees
€ 1 796,07 ex VAT
€ 1 796,07 w/ VAT
pc
Add to compare list
  1. Parameters

Detailed information





 Chassis Manual  Drive Options

Key Features

Cloud Backup, Data Replication, or High Density Archive Storage Applications

    1. 3U Storage JBOD Chassis with capacity 16 x 3.5" hot-swappable HDDs bays
    2. Single Expander Backplane Boards support SAS3/2 HDDs with 12Gb/s throughput
    3. 4 x Mini-SAS HD ports for Internal / External Cascading Expander Combination for high performance, high availability or high redundancy requirements
    4. 1x IPMI port for Remote System Power on/off and system monitoring
    5. Support NTP for time synchronization & RTC battery backup
    6. 1000W (1+1) 96% efficient Titanium level power supplies
    7. 5 hot-plug redundant cooling fans
    8. Ideal for Cloud backup, data Replication or High desnsity Archive Storage Applications
    9. Qualified SAS HBA / controller:

AOC-SAS3-9300-8E
     - 12Gb/s 2-external ports SAS3 HBA

AOC-SAS3-9380-8E
     - 12Gb/s 2-external ports SAS3 RAID Controller




For optimal performance and quality, Supermicro validated drives are recommended. Please contact your Supermicro sales rep for validated HDD.

Product SKUs
CSE-836BE1C-R1K03JBOD
  • SuperChassis 836BE1C-R1K03JBOD

Form Factor
  • 3U JBOD storage chassis

Dimensions
Height
  • 5.2" (132 mm)
Width
  • 17.2" (437 mm)
Depth
  • 25.5" (647 mm)
Net Weight
  • 55 lbs (24.95 kg)
Gross Weight
  • 80 lbs (36.29 kg)
Packaging (W x H x L)
  • 26.6" (676 mm) x 13" (330 mm) x 39.9" (1013 mm)
Available Color
  • Black

Drive Bays
  • 16 x 3.5" hot-swap HDD bays for JBOD solution

Qualified SAS Controllers
  • AOC-SAS3-9300-8E: SAS 12Gb/s PCIe 3.0 8-Port Host Bus Adapter
  • AOC-SAS3-9380-8E: SAS 12Gb/s PCIe 3.0 8-Port MegaRAID Controller

Backplane
  • 16-port 3U SAS3 12Gbps single-expander backplane, support up to 16x 3.5-inch SAS3/SATA3 HDD/SSD

Front Panel
Buttons
  • Power On/Off button
  • System Reset Button
  • Unit Identification (UID) button
LEDs
  • 1 Network Activity LEDs
Systems Cooling
Fans
  • 3 x 8cm hot-swap redundant PWM cooling fan(s)
  • 2 x 8cm hot-swap exhaust fan(s) & air shroud

System Monitoring
  • IPMI

Operating Environment (System)
Operating Temperature Range
  • 5°C - 35°C (41°F - 95°F)
Non-Operating Temperature Range
  • -40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range
  • 8% - 90% (non-condensing)
Non-Operating Relative Humidity Range
  • 5% - 95% (non-condensing)

Power Supply
1U 800/1000W Redundant Titanium Single Output Power Supply W/PMbus
Power Efficiency
  • 96%
Total Output Power and Input
  • 800W with Input 100 - 127Vac
  • 1000W with Input 200 - 240Vac
  • 1000W with Input 200 - 240Vdc
AC Input Frequency
  • 50-60Hz
Dimensions (L x W x H)
  • 336 x 76 x 40 mm
Output Type
  • Backplanes (gold finger)
+12V
  • Max: 66.7A (100Vac - 127Vac)
  • Max: 83A (200Vac - 240Vac)
  • Max: 83A (200 - 240)
+5Vsb
  • Max: 4A / Min: 0A
Power Distributor
  • PDB-PT826-8824
  • O/P: 12V/135A
  • +5V Max: 40A
  • +3.3V Max: 24A
  • -12V Max: 0.6A
Certification
  • Titanium Certified  Titanium Certified

Regulatory (Power Supply)
Power Supply Safety / EMC
  • BSMI
  • CCC
  • CE/EMC
  • FCC class A
  • UL/CB
  • UL/CUL
Standard Parts List
  Part Number Qty Description
Air Shroud MCP-310-39001-0N 1 SC835/836/936 Intel DP X9-X10 PC air shroud 1368x13/12x13MB
HD Backplane BPN-SAS3-836EL1 1 16-port 3U SAS3 12Gbps single-expander backplane, support up to 16x 3.5-inch SAS3/SATA3 HDD/SSD
Control Board CSE-PTJBOD-CB3 1 JBOD chassis power control board with IPMI remote on/off feature
Cable(S) CBL-0071L 1 CBL,FRONT CNTL,16 TO 16 PIN,RA,RND TUBE,75CM,28AWG
Cable(S) CBL-0088L 1 4 PIN MIDDLE FAN POWER CABLE (PWM). 27cm, 24AWG
Cable(S) CBL-0296L 2 4 pin to 4 pin fan extension cord, for PWM fan. 23cm. 24AWG
Cable(S) CBL-CDAT-0601 1 CBL,I2C,1X4F/P2.5 TO 1X4F/P2.5,50CM,26AWG,BRN/BLK-SHUNT/ORG
Cable(S) CBL-NTWK-0587 1 INT RJ45M/RJ45F Adapter W/ PCB 50CM 24AWG for SC847D JBOD
Cable(S) CBL-SAST-0532 4 MINI SAS HD,12G,INT,50CM,30AWG
CD-ROM & Accessory MCP-290-00007-01 1 Black DVD dummy cover for SC825, 836
Fan(s) FAN-0125L4 2 80x32 mm 6.7K RPM SC836 Rear Exhaust Fan w/ Housing
Fan(s) FAN-0126L4 3 80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing
Drive Tray(s) MCP-220-00007-01 1 Black USB/COM port tray for SC825, 836
Drive Tray(s) MCP-220-00075-0B 16 Black gen 5.5 hot-swap 3.5"; HDD tray
Power Distributor PDB-PT826-8824 1 PDB with longer 24pin for SC826B
Part(s) MCP-260-00011-0N 1 I/O shield without any opening
Part(s) MCP-290-83601-0V 1 set Silver chassis handles (left and right) for SC836/835
Power Supply & Accessory PWS-1K03A-1R 2 1U 1000W Redundant Power Supply Titanium W/PMbus 76x40x336mm,RoHS/REACH
Mounting Rail(s) MCP-410-00007-0N 1 Rail screw bag
Mounting Rail(s) MCP-290-00053-0N 1 Rail set, quick/quick, default for 2,3U 17.2";W
Rear Window MCP-240-83605-0N 1 836B chassis rear window (to support the optional MCP-220-83605-0N)

Parameters

Size in U 3
Depth (mm) 647
CPU manufacturer
Socket
HDD disks 16
2.5" Drive bays 0
3.5" Drive bays 16
NVMe slots 0
Total amount of PCIe
OCP/AIOM
Power (W) 1000
Efficiency certification Titanium
