ASUS RS720-E10-RS24U/10G/2.4KW/24NVMe (Label change) - 90SF00Z3-M02BY0
ASUS RS720-E10-RS24U/10G/2.4KW/24NVMe (Label change) - 90SF00Z3-M02BY0
2U dual-socket server powered by 3rd Gen Intel Xeon Scalable processors that supports up to 32 DIMMs, 24 NVMe, nine PCIe 4.0 slots, OCP 3.0, dual M.2 and ASUS ASMB10-iKVM
We also offer six months of free collocation in our TIER III data center.
Components are not the end — ask us for a custom server configuration. We will design the server, assemble it, expertly set it up, and provide extended or NBD warranty.
| Product code | 202.172059 |
|---|---|
| Part number | 90SF00Z3-M02BY0 |
| EAN | 4711387567975 |
| Manufacturer | ASUS |
| Availability | Not in stock |
| Warranty | 36 months |
| Weight | 21.69 kg |
| The price includes all legal fees | |
Detailed information
3rd Gen Intel® Xeon® Scalable Processors
The latest 3rd Gen Intel® Xeon® Scalable Processors feature core counts from 8 to 40 cores and an array of frequency and power supports, and deliver up to 40% better performance compared to the previous generations. With built-in security features, this new platform delivers outstanding performance in security including encryption, authentication and data integrity across the breadth of standards that are prevalent in networking, enterprise and the cloud.
The latest 3rd Gen Intel® Xeon® Scalable Processors feature core counts from 8 to 40 cores and an array of frequency and power supports, and deliver up to 40% better performance compared to the previous generations. With built-in security features, this new platform delivers outstanding performance in security including encryption, authentication and data integrity across the breadth of standards that are prevalent in networking, enterprise and the cloud.
PCIe 4.0 Ready
PCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. ASUS RS720-E10 servers are PCIe 4.0 ready to support a diverse array of graphics, storage and networking – enabling flexible scalability for demanding or increasing workloads.
PCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. ASUS RS720-E10 servers are PCIe 4.0 ready to support a diverse array of graphics, storage and networking – enabling flexible scalability for demanding or increasing workloads.
Up to
1.5 x
General compute performance gain
Up to
64 lanes
PCI Express 4 (per socket)
40 cores
Up to 1.42X more cores
-
- Processor
CPU 3rd Gen Intel® Xeon® Scalable Processors Family Socket 2 x Socket P+ (LGA 4189) - System memory
Memory maximum Capacity Up to 8TB DIMM
Up to 12TB DIMM+PMEM (200 series)Memory Slots 32 (8-channel per CPU, 16 DIMM per CPU) Memory Type DDR4 3200/2933 RDIMM
DDR4 3200/2933 LRDIMM
DDR4 3200/2933 LR-DIMM 3DS
3200/2933- Expansion slots
PCIe Up to 9 x Expansion slots
2 x PCIe Gen4 x8 or 1 x PCIe Gen4 x16, FHFL (CPU1 x1)
1 x PCIe Gen4 x8, FHFL (CPU1 x1)
1 x PCIe Gen4 x16, FHFL or OCP 3.0 NIC socket (CPU1 x1)
4 x PCIe Gen4 x8 or 2 x PCIe Gen4 x16, FHFL (CPU2 x2)
1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2 x1)- Storage
Drive Bays Front bays:
24 x 2.5" hot-swap bays (12x NVMe + 12x SATA/SAS* or 12x NVMe + 12x NVMe/SATA/SAS*)M.2 2 x M.2 connector (NGFF 2280/2260. PCIe Gen4x4 link) - Networking
Networking 1 x Quad Port Intel I350-AM4 1G LAN Controller + 1 x Mgmt LAN
or
Option 2
1 x Dual Port Intel X710-AT2 Gigabit 10G LAN Controller + 1 x Mgmt LAN
or
None x + 1 x Mgmt LAN- Graphic
Graphic Aspeed AST2600 with 64MB VRAM
-
- I/O Ports
Front I/O Ports 2 x USB 3.2 Gen1 ports Rear I/O Ports 2 x USB 3.2 Gen1 ports
1 x VGA port
1 x RJ-45 Mgmt LAN port
4/2 x NIC ports- Switch/LED
Front Switch/LED 1 x Power switch/LED
1 x Location switch/LED
1 x Reset switch
1 x HDD Access LED
1 x Message LED
LAN 1-4 LEDRear Switch/LED 1 x Power switch
1 x Q-Code/Port 80 LED
1 x Location LED- Cooling
System Fans 4 CPU Heatsink/ Cooler 2 Fan 1 (For supporting GPU SKU, it will have external fan) - Dimensions
Form Factor 2U Height 88mm Width 449mm Depth 840mm Weight 21.69 kg - Power supply
Certification Titanium/Platinum Power 2400W/1600W QTY 1+1
Parameters
| Size in U | 2 |
|---|---|
| Depth (mm) | 840 |
| CPU manufacturer | Intel |
| Socket | 4189 |
| HDD disks | 26 |
| 2.5" Drive bays | 24 |
| 3.5" Drive bays | 0 |
| NVMe slots | 26 |
| Total amount of PCIe | 9 |
| OCP/AIOM | 1 |
| Power (W) | 2400 |
| Efficiency certification | Titanium |
