ASUS ESC4000-E10-SKU3/2200W(1+1) / 8NVMe - 90SF01B3-M00EU0
ASUS ESC4000-E10-SKU3/2200W(1+1) / 8NVMe - 90SF01B3-M00EU0
2U GPU server powered by dual-socket 3rd Gen Intel Xeon Scalable processors that supports up to 16 DIMM, four dual-slot GPU, 4 M.2, eight NVMe (by SKU), total eleven PCIe 4.0 slots, one OCP 3.0 (by SKU) and ASUS ASMB10-iKVM.
We also offer six months of free collocation in our TIER III data center.
Components are not the end — ask us for a custom server configuration. We will design the server, assemble it, expertly set it up, and provide extended or NBD warranty.
| Product code | 202.163631 |
|---|---|
| Part number | 90SF01B3-M00EU0 |
| EAN | 4711081997863 |
| Manufacturer | ASUS |
| Availability | Not in stock |
| Warranty | 24 months |
| Weight | 44 kg |
| The price includes all legal fees | |
Detailed information
3rd Gen Intel® Xeon® Scalable Processors
The latest 3rd Gen Intel® Xeon® Scalable Processors feature core counts from 8 to 40 cores and an array of frequency and power supports, and deliver up to 40% better performance compared to the previous generations. With built-in security features, this new platform delivers outstanding performance in security including encryption, authentication and data integrity across the breadth of standards that are prevalent in networking, enterprise and the cloud.
The latest 3rd Gen Intel® Xeon® Scalable Processors feature core counts from 8 to 40 cores and an array of frequency and power supports, and deliver up to 40% better performance compared to the previous generations. With built-in security features, this new platform delivers outstanding performance in security including encryption, authentication and data integrity across the breadth of standards that are prevalent in networking, enterprise and the cloud.
Up to
1.5x
General compute performance gain
Up to
64 lanes
PCI Express 4 (per socket)
40 cores
Up to 1.42X more cores
PCIe 4.0 Ready
PCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. ASUS RS720A-E11 servers are PCIe 4.0 ready to support a diverse array of graphics, storage and networking – enabling flexible scalability for demanding or increasing workloads.
PCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. ASUS RS720A-E11 servers are PCIe 4.0 ready to support a diverse array of graphics, storage and networking – enabling flexible scalability for demanding or increasing workloads.
-
- Processor
CPU 3rd Gen Intel® Xeon® Scalable Processors Family(205W) Socket 2 x Socket P+ (LGA 4189) Core Logic Intel® PCH C621A - System memory
Memory maximum Capacity Up to 4,096GB DIMM
Up to 6,144GB DIMM+PMem (200 series)Memory Slots 16 (8-channel, 1DPC) Memory Type DDR4 3200 RDIMM / LRDIMM / LRDIMM 3DS - Expansion slots
Rear - 4 x PCIe x16 slots (Gen4 x16 link, FH,FL) for dual-slot GPU cards or
8 x PCIe x16 slots (Gen4 x8 link, FH,FL) for single-slot GPU cards*
- 2 x PCIe x16 slots (Gen4 x16 link, LP,HL)Front - SKU-1:
1 x PCIe x8 slot (Gen4 x8 link, LP,HL)
4 x M.2 sockets (Gen4 x4 link, up to 22110 module)
- SKU-2:
1 x PCIe x8 slot (Gen4 x8 link, LP,HL)
1 x OCP3.0 slot (Gen4 x16 link)
- SKU-3:
8 x 3.5” NVMe support- Storage
Drive Bays 8 x 3.5" Hot-swap Storage Bays M.2 1 x M.2 socket (Gen3 x4 link or SATA mode, up to 2280 on-motherboard) Notes (SKU-1 & SKU-2 Backplane Supports 6 x SATA/SAS + 2 x SATA/SAS/NVMe Devices**)
(SKU-3 Backplane Supports 8 x SATA/SAS/NVMe DevicesStorage Controller Intel® PCH C621A Optional kits Controller ASUS PIKE II 3008-8i 8-port SAS 12G HBA card
ASUS PIKE II 3108-8i 8-port SAS 12G RAID card- Networking
Networking 2 x 1GbE LAN ports (RJ45, Intel I350-AM2)
-
- I/O Ports
Front I/O Ports 4 x USB 3.2 Gen1 ports Rear I/O Ports 2 x USB 3.2 Gen1 ports
1 x VGA port
2 x 1GbE LAN ports (RJ45)
1 x Management port (RJ45)- Switch/LED
Front 1 x Power Button/LED
1 x Location Button/LED
2 x LAN LED
1 x Message LED
1 x HDD Access LEDRear 1 x Power Button/LED
1 x Location LED
1 x Message LED
1 x HDD Access LED- Management Solution
Management Solution ASUS Control Center Enterprise (in-band)
ASMB10-iKVM (out-of-band/BMC AST2600)Regulatory Compliance BSMI, CB, CE, RCM, FCC(Class A) - Dimensions
Form Factor 2U Height 88.9mm Width 440mm Depth 800mm Weight 44 Kg
- Power supply
Certification Power 1+1 Redundant 2200W 80 PLUS TITANIUM Power Supply C-20 power inlet
Parameters
| Size in U | 2 |
|---|---|
| Depth (mm) | 800 |
| CPU manufacturer | Intel |
| Socket | 4189 |
| HDD disks | 9 |
| 2.5" Drive bays | 0 |
| 3.5" Drive bays | 8 |
| NVMe slots | 9 |
| Total amount of PCIe | 7 |
| OCP/AIOM | 1 |
| Power (W) | 2200 |
| Efficiency certification | Titanium |
