AIC RSC-2MS - XE1-2MS00-04
2U chassis 24x 3.5" SAS/SATA hot-swap, 4x 2.5" 15mm NVMe hot-swap (customized MB I/O required), 4x 6038 fan module, 3Y 1U 600W Platinum redundant power supply, with 6x mini SAS HD cable (for RAID adapter connection to 24x 3.5" hot-swap), with slide rail
We also offer six months of free collocation in our TIER III data center.
| Product code | 202.179553 |
|---|---|
| Part number | XE1-2MS00-04 |
| Manufacturer | AIC |
| Availability | Not in stock |
| Warranty | 36 months |
| Weight | 31 kg |
| The price includes all legal fees | |
Detailed information
AIC Servers
AIC's offers heavy-duty EMI-RFI-resistant industrial computer enclosures. Their scalable and cost-effective enclosure solutions encompass server and storage enclosures in a variety of form factors and specifications. AIC enclosures are designed to support the latest technology platforms in the market today, ensuring maximum compatibility with products from other component vendors.
Invest in Certainty
AIC, with over 30 years of experience, offers unmatched flexibility and scalability in the market. Its wide range of products allows maximum customization according to individual customer needs. With the trust the company places in its solutions, it provides extended warranties on its products for 5 years and more. The combination of efficient and modern design positions AIC at the forefront of the market, enabling it to quickly gain recognition in the mainstream.
-
Dimensions
(W x D x H)mm : 438 x 838 x 88
inches : 17.2 x 33 x 3.46Industry Standard EIA-RS310D Material SGCC Color Front Panel : No coating Cooling 4 x 60x38mm PWM fans Power Supply 600W 1+1 redundant PSU PMBus 1.2 80+ Platinum Expansion Slots 7 low profile Front Panel System power switch and System reset switch LED Indicators System power, HDD, LAN 1 and LAN 2
-
System Board Up to 12” x 10.5” ATX M/B Drive Bays Internal:
24x 3.5" SAS/SATA Hot-Swap
External:
4x 2.5" 15mm NVMe Hot-SwapBackplane 6 x 4-port SATA/SAS backplanes with SFF-8643 connectors Storage Temperature 0ºC (32ºF) ~ 50ºC (122ºF) Humidity 5% ~ 95% non-condensing Weight kgs : 31
lbs : 68.35Packaging Dimensions
(W x D x H)mm : 584 x 1015 x 254
inches : 23 x 39.9 x 10Cubic Feet 7.9 Container Load Quantity 20’ 126
40’ 266
40’ H 304Mounting Standard 33” slide rail
